EPC1 Modular Contactors 2 & 4 Pole
AC-1 Contactors 24VAC or 230VAC coils as noted
| Part Code | Specification | Datasheet | SDoC |
|---|---|---|---|
| EPC1-25-20-230 | 25A 2NO 1M 230VAC | EPC1-25 2 Pole 24V/230V Datasheet | EPC1-25 2 & 4 Pole SDoC |
| EPC1-25-20-24 | 25A 2NO 1M 24VAC | ||
| EPC1-25-11-230 | 25A 1NO+1NC 1M 230VAC | ||
| EPC1-25-02-230 | 25A 2NC 1M 230VAC | ||
| EPC1-25-40-230 | 25A 4NO 2M 230VAC | EPC1-25 4 Pole 24V/230V Datasheet | |
| EPC1-25-40-24 | 25A 4NO 2M 24VAC | ||
| EPC1-25-22-230 | 25A 2NO+2NC 2M 230VAC | ||
| EPC1-25-31-230 | 25A 3NO+1NC 2M 230VAC | ||
| EPC1-25-04-230 | 25A 4NC 2M 230VAC | ||
| EPC1-40-20-230 | 40A 2NO 2M 230VAC | EPC1-40 2 Pole 230V Datasheet | EPC1-40-63 2 & 4 Pole SDoC |
| EPC1-40-11-230 | 40A 1NO+1NC 2M 230VAC | ||
| EPC1-40-02-230 | 40A 2NC 2M 230VAC | ||
| EPC1-40-40-230 | 40A 4NO 3M 230VAC | EPC1-40 4 Pole 230V Datasheet | |
| EPC1-40-22-230 | 40A 2NO+2NC 3M 230VAC | ||
| EPC1-40-31-230 | 40A 3NO+1NC 3M 230VAC | ||
| EPC1-40-04-230 | 40A 4NC 3M 230VAC | ||
| EPC1-63-20-230 | 63A 2NO 2M 230VAC | EPC1-63 2 Pole 230V Datasheet | |
| EPC1-63-11-230 | 63A 1NO+1NC 2M 230VAC | ||
| EPC1-63-02-230 | 63A 2NC 2M 230VAC | ||
| EPC1-63-04-230 | 63A 4NC 3M 230VAC | EPC1-63 4 Pole 230V Datasheet | |
| EPC1-63-22-230 | 63A 2NO+2NC 3M 230VAC | ||
| EPC1-63-31-230 | 63A 3NO+1NC 3M 230VAC | ||
| EPC1-63-40-230 | 63A 4NO 3M 230VAC |
Where several part codes share a datasheet or SDoC, the document is linked once for that group.
